Sub 1GHz Multichannel Radio Transceiver Module 433MHz SMT Version RC-CC1101-SPI-SMT434 CC1101
It is a low-cost sub 1GHz multichannel transceiver designed for low-consumption wireless applications. The hardware is based on Texas Instruments CC1101 component. Programmable from external microcontroller via SPI interface. Working frequency programmable in the following band: 433MHz
Please refer to the CC1101 Texas Instruments datasheet for more information and details.
Mechanical Dimensions : 15 x 18mm
| Technical Characteristics | MIN | TYP | MAX | UNIT |
| Supply Voltage | 1.8 | 3.0 | 3.60 | Volt |
| Current Consumption (RX mode/TX Mode) | 18/30 | 6.8 | mA | |
| Current Consumption Power down mode | 0.2 | µA | ||
| Frequency | 433 | MHz | ||
| RF Power Output 50ohm | +10 | dBm | ||
| RF Sensitivity (1.2 Kb/sec data rate) | -112 | dBm | ||
| Data Rate | 1.2 | 500 | Kbit/s | |
| Tolerance Receiver Frequency | ±1.5 | KHz | ||
| Frequency deviation | ±1.5 | ±380 | KHz | |
| Operating Temperature range | -20 | +70 | °C |
